Type 082 (Wosao Class) Coastal Minesweeper

中国082型(Wosao级)港湾扫雷舰

Date:2013-10-26 Source:internet By:globalmil Viewed:

The Type 082 (NATO reporting name: Wosao class) is a coastal minesweeper introduced by the PLA Navy in the 1980s. The vessel is fitted with a Type 316 small mechanical sweep gear, a Type 317 magnetic generator, and a Type 318 acoustic generator. The vessel is powered by two 12V180-1 diesels and is operated by a crew of 28 men. Its armaments include two Type 61 dual-25mm AAA guns.

082型(北约代号命名:Wosao级)是在1980年PLA海军服役的港湾扫雷艇。配备有316型小型机械扫雷具,317型电磁扫雷具和318型音响扫雷具。安装二台12V180-1型柴油发动机,乘员28名。它装备包括二门61型双-25毫米AAA炮。

Shiplist

船只目录



Hull No.(弦号)
Name(命名)
Fleet(舰队)
800


801
Xiangshan(象山)

802


803


806



Specifications

Displacement: (standard) 305 tonnes; (full load) 313.5 tonnes
Dimensions: Length: 44.79; Beam: 6.2m; Draft: 2.25m
Propulsion: 2X 12V180-1 diesels, 2 shafts, 2,000bhp
Speed: Maximum 15.5 knots; Economic 8 knots; Minesweeping operation: 2~12 knots
Range: 500nm@8 knots
Endurance: 15 days
Crew: 28
Armament: 2 Type 61 dual-25 mm, minerails

规格

排水量: (标准)305 吨;(满载)313.5 吨
尺寸: 长度: 44.79;宽度: 6.2 米;吃水线: 2.25 米
推进: 2 X 12V180-1型 柴油发动机, 2 轴,2,000 马力
航速: 最大 15.5 节;经济 8 节;扫雷操作: 2~12 节
航程: 500 海里@8 节
续航力: 15 天
组员: 28 名
装备: 2门61型 双-25毫米,扫雷装备

Last update: 14 June 2008
最后更新: 2008年6月14日
