Type 032 submarine

中国海军032型实验潜艇

Date:2016-08-09 Source:wikipedia By:Globalmil Viewed:

032型潜艇 上万千米导弹试验全靠它

The Type 032 submarine (NATO reporting name: Qing-class) is a class of diesel-electric submarine currently undergoing testing in China's People's Liberation Army Navy. It is said to be the world's largest conventional submarine, at a submerged displacement of 6,628 tonnes and is able to submerge for a maximum of 30 days.
032型潜艇(北约代号:清级)是柴电潜艇的一个级别目前中国人民解放军海军正在进行测试。它被认为是世界上最大的常规潜艇,水下排水量6628吨,能够最长航行30天。

Design
设计

The Type 032 has a similar ventral "bay" to the Golf-class submarine that protrudes downward.[2] The project for this double hulled submarine begun in January 2005, and construction begun at Wuhan Shipyard in 2008. The submarine was launched on September 10, 2010, and sea trials were completed in September 2012. The submarine entered service on October 12, 2012 with pennant number 201.
032型也有类似高尔夫级(629型)的腹部“凸窗”的潜艇下方突出。在2005年1月开始这艘双壳潜艇项目,在2008年武汉造船厂开始建造,潜艇在2010年9月10日下水,在2012年9月完成海试,潜水艇在2012年10月12日进入服役,舷号201。

032型潜艇 上万千米导弹试验全靠它

032型潜艇 上万千米导弹试验全靠它

The submarine is a testbed for new technologies such as combustion powered torpedoes, compartments for special forces, underwater unmanned vehicles, new SLBMs, new cruise missiles, new anti ship missiles, new SAMs, and a new escape pod which are applied to the Type 095 and Type 096 submarines.
该潜艇是用于新技术的一个测试平台,如热动力鱼雷,特种作战隔舱,水下无人航行器,新型潜射弹道导弹,新型巡航导弹,新型反舰导弹,新型地空导弹,以及已被用于095型和096型潜艇的一个新的逃生舱。

Specifications are as follows:
规格如下:

Length (m): 92.6
Beam (m): 10
Height (m): 17.2
Draft (m): 6.85
Surfaced displacement (t): 3797
Submerged displacement (t): 6628
Operating depth (m): 160
Max depth (m): 200
Surface speed (kt): 10
Submerged speed (kt): 14
Compliment: 88 crew and around 100 scientists and researchers
Endurance (day): 30 for 88 compliment, 5 for 130 compliment, and 3 for 200 compliment
Torpedo: two torpedo tubes (TT) in the bow, with one 650 mm TT on starboard side and one 533 mm TT on port side
Missile: three vertical launching system (VLS) tubes for submarine launched ballistic missiles in the conning tower,[6] four VLS tubes for cruise/ASW/AShM missiles in the forward section.[7]
Design: double-hull

长度:92.6米
艇宽:10米
艇高:17.2米
吃水线:6.85米
水上排水量:3797吨
水下排水量:6628吨
工作深度:160米
最大深度:200米
水面航速:10节
潜行航速:14节
全体人员:88名乘员和100名科学家和研究人员
续航力:30名人员时88天,130人员时5天,200名人员时3天
鱼雷:两具鱼雷发射管(TT)在潜艇头部,一具650毫米鱼雷发射管(TT)在右舷和一具 533毫米鱼雷发射管(TT)在左舷
导弹:指挥塔有三个垂直发射系统(VLS)管潜艇用于发射弹道导弹,在潜艇前部有四个 VLS管用于巡航/反潜(ASW)/反舰(ASHM)导弹。
设计:双壳体
